Double color extrusion type Polycarbonate Body Up to 130LM / W Fast connecting external wire Impact Rating IK08 Emergency or Sensor option 3 YEAR Warranty
Product Description
|
ITEM NO. |
POWER |
LUMEN |
CCT |
CRI |
PF |
LEDS QTY |
QTY/CTN |
DIMENSION(L*W*H |
|
FG06-106 |
18W |
1800LM |
3000-6500K |
>80 |
>0.9 |
96PCS |
9PCS |
680*101*83MM |
|
FG06-112 |
36W |
3600LM |
3000-6500K |
>80 |
>0.9 |
192PCS |
6PCS |
1280*101*83MM |
|
FG06-115 |
48W |
4800LM |
3000-6500K |
>80 |
>0.9 |
240PCS |
6PCS |
1580*101*83MM |
Voltage: 220-240V 50/60Hz
IP Rate: IP65 IK08 Class II
Housing material: PC
Reflector: Steel sheet with white power coating
LED Driver: Non-isolation driver
LED: SMD2835
Mounting bracket: Stainless steel brackets;
Terminal block : fast connecting external wiring
Installation: Easy and quick to install under ceiling or on surface.
Accessory bag: Rubber grommet, expansion pipe and screws
Working temperature: -20 - +40℃
Lifetime: 25000hours
Indoor and outdoor application places, waterproof, dustproof, anti-corrosive
Warm tips:
1) shall not be installed on the surface where there is strong vibration.
2) when using PC diffuser, do not use strong alkaline, acidic or cleaning agent attack PC material.
3) for special use, please contact us.
